3 Introduction of Products (Compliant with Overseas Standards)
3.1 List of Products (to be Connected) and Interpretation of Model Names
3.1.10 [M] FX Series terminal blocks (cables and connectors)
1. FX Series terminal blocks
 : Compliance with standard or self-declaration  : Not targeted − : Not applicable
→ For more information on CE, UL and cUL, refer to Page 15 or later.
2. Input/output cables
3. Input/output connector
3.1.11 [N] Remote I/O
For the remote I/O of CC-Link, CC-Link/LT and AS-i system, refer to the manual and catalog of each master.
3.1.12 [O] Power supply unit
 : Compliance with standard or self-declaration  : Not targeted − : Not applicable
→ For more information on CE, UL and cUL, refer to Page 15 or later.
Model name
Number
of input
points
Number
of
output
points
Function
CE
UL
cUL
Marine
EMC LVD
FX-16E-TB
16 input points or
16 output points
To be directly connected to the PLC
input/output connector
−− −
FX-32E-TB
32 input points,
32 output points or
16 input/output
points
−− −
FX-16EX-A1-TB 16 − 100V AC input −− −
FX-16EYR-TB − 16 Relay output −− −
FX-16EYS-TB − 16 Triac output −−−−
FX-16EYT-TB − 16 Transistor output (sink) −− −
FX-16EYT-H-TB − 16 Transistor output (sink) −−−−
Model name Shape
FX-16E-500CAB-S 5m(16’4")
• Single wire (Wire color: red)
• PLC side: A 20-pin connector
FX-16E-150CAB 1.5m(4’11")
• Flat cables (with tube)
• A 20- pin connector at both ends
FX-16E-300CAB 3m(9’10")
FX-16E-500CAB 5m(16’4")
FX-16E-150CAB-R 1.5m(4’11")
• Round multicore cables
• A 20-pin connector at both ends
FX-16E-300CAB-R 3m(9’10")
FX-16E-500CAB-R 5m(16’4")
FX-A32E-150CAB 1.5m(4’11") • Flat cables (with tube)
• PLC side: Two 20-pin connectors in 16-point units.
• Terminal block side: A dedicated connector
• One common terminal covers 32 input/output terminals.
FX-A32E-300CAB 3m(9’10")
FX-A32E-500CAB 5m(16’4")
Model name Function
FX2C-I/O-CON 10-piece set Input/output connector for flat cable
FX2C-I/O-CON-S 5-piece set
Input/output connector for bulk wire for 0.3 mm
2
[AGW22]
FX2C-I/O-CON-SA 5-piece set
Input/output connector for bulk wire for 0.5 mm
2
[AGW20]
Model name Description
Driving power
supply
CE
UL
cUL
Marine
EMC LVD
FX2N-20PSU 24V DC power supply 100 to 240V AC  −
M
N
O
