FX3U Series Programmable Controllers
User’s Manual - Hardware Edition
138
7 Assignment of Input/Output Numbers (X/Y) and Unit Numbers
7.2 Unit Numbers of Special Function Units/Blocks
7.2 Unit Numbers of Special Function Units/Blocks
7.2.1 Concept of assigning
When power is turned on, the main unit (CPU) automatically assigns the numbers 0 to 7 to special function
units/blocks starting from the one closest to the main unit.
Unit numbers are not given to input/output powered extension units/blocks.
1. Special function units/blocks connected to main unit
The numbers 0 to 7 are assigned to the special function units/blocks starting from the one closest to the main
unit.
2. FX2N-1RM(-E)-SET
Up to three FX2N-1RM(-E)-SET can be sequentially connected to the end of one system.
All these connected units have the same number as the unit number of the first unit (FX2N-1RM(-E)-SET).
→ For FX2N-1RM-E-SET, refer to FX2N-1RM-E-SET USER’S MANUAL.
3. Products to which unit numbers are not assigned
• Input/output powered extension units: FX2N-32ER-ES/UL, FX2N-48ET-ESS/UL, etc.
• Input/output extension blocks: FX2N-16EX-ES/UL, FX2N-16EYR-ES/UL, etc.
• Special function block: FX2N-16LNK-M
• Connector conversion adapter: FX2N-CNV-BC
• Expansion boards: FX3U-232-BD, etc.
• Special adapters: FX3U-232ADP, etc.
• Extension power supply unit: FX3U-1PSU-5V
