FX3U Series Programmable Controllers
User’s Manual - Hardware Edition
A Operation of Special Devices (M8000 -, D8000 -)
A-3 Analog special adapters [M8260 to M8299 and D8260 to D8299]
Number
Operation and function
FX3U-4AD-PT(W)ADP FX3U-4AD-TC-ADP FX3U-4AD-PNK-ADP
Applicable version
From first version From first version From first version
1st analog special adapter
D 8260 Measured temperature Ch1 Measured temperature Ch1 Measured temperature Ch1
D 8261
Measured temperature Ch2 Measured temperature Ch2 Measured temperature Ch2
D 8262
Measured temperature Ch3 Measured temperature Ch3 Measured temperature Ch3
D 8263
Measured temperature Ch4 Measured temperature Ch4 Measured temperature Ch4
D 8264
Number of averaging times for Ch1
(1 to 4095)
Number of averaging times for Ch1
(1 to 4095)
Number of averaging times for Ch1
(1 to 4095)
D 8265
Number of averaging times for Ch2
(1 to 4095)
Number of averaging times for Ch2
(1 to 4095)
Number of averaging times for Ch2
(1 to 4095)
D 8266
Number of averaging times for Ch3
(1 to 4095)
Number of averaging times for Ch3
(1 to 4095)
Number of averaging times for Ch3
(1 to 4095)
D 8267
Number of averaging times for Ch4
(1 to 4095)
Number of averaging times for Ch4
(1 to 4095)
Number of averaging times for Ch4
(1 to 4095)
D 8268 Error status Error status Error status
D 8269
Model code: K20 (PT), K21 (PTW) Model code: K10 Model code: K11
2nd analog special adapter
D 8270
Measured temperature Ch1 Measured temperature Ch1 Measured temperature Ch1
D 8271
Measured temperature Ch2 Measured temperature Ch2 Measured temperature Ch2
D 8272
Measured temperature Ch3 Measured temperature Ch3 Measured temperature Ch3
D 8273
Measured temperature Ch4 Measured temperature Ch4 Measured temperature Ch4
D 8274
Number of averaging times for Ch1
(1 to 4095)
Number of averaging times for Ch1
(1 to 4095)
Number of averaging times for Ch1
(1 to 4095)
D 8275
Number of averaging times for Ch2
(1 to 4095)
Number of averaging times for Ch2
(1 to 4095)
Number of averaging times for Ch2
(1 to 4095)
D 8276
Number of averaging times for Ch3
(1 to 4095)
Number of averaging times for Ch3
(1 to 4095)
Number of averaging times for Ch3
(1 to 4095)
D 8277
Number of averaging times for Ch4
(1 to 4095)
Number of averaging times for Ch4
(1 to 4095)
Number of averaging times for Ch4
(1 to 4095)
D 8278
Error status
Error status Error status
D 8279
Model code: K20 (PT), K21 (PTW) Model code: K10 Model code: K11
3rd analog special adapter
D 8280 Measured temperature Ch1 Measured temperature Ch1 Measured temperature Ch1
D 8281
Measured temperature Ch2 Measured temperature Ch2 Measured temperature Ch2
D 8282
Measured temperature Ch3 Measured temperature Ch3 Measured temperature Ch3
D 8283
Measured temperature Ch4 Measured temperature Ch4 Measured temperature Ch4
D 8284
Number of averaging times for Ch1
(1 to 4095)
Number of averaging times for Ch1
(1 to 4095)
Number of averaging times for Ch1
(1 to 4095)
D 8285
Number of averaging times for Ch2
(1 to 4095)
Number of averaging times for Ch2
(1 to 4095)
Number of averaging times for Ch2
(1 to 4095)
D 8286
Number of averaging times for Ch3
(1 to 4095)
Number of averaging times for Ch3
(1 to 4095)
Number of averaging times for Ch3
(1 to 4095)
D 8287
Number of averaging times for Ch4
(1 to 4095)
Number of averaging times for Ch4
(1 to 4095)
Number of averaging times for Ch4
(1 to 4095)
D 8288 Error status Error status Error status
D 8289
Model code: K20 (PT), K21 (PTW) Model code: K10 Model code: K11
4th analog special adapter
D 8290 Measured temperature Ch1 Measured temperature Ch1 Measured temperature Ch1
D 8291
Measured temperature Ch2 Measured temperature Ch2 Measured temperature Ch2
D 8292
Measured temperature Ch3 Measured temperature Ch3 Measured temperature Ch3
D 8293
Measured temperature Ch4 Measured temperature Ch4 Measured temperature Ch4
D 8294
Number of averaging times for Ch1
(1 to 4095)
Number of averaging times for Ch1
(1 to 4095)
Number of averaging times for Ch1
(1 to 4095)
D 8295
Number of averaging times for Ch2
(1 to 4095)
Number of averaging times for Ch2
(1 to 4095)
Number of averaging times for Ch2
(1 to 4095)
D 8296
Number of averaging times for Ch3
(1 to 4095)
Number of averaging times for Ch3
(1 to 4095)
Number of averaging times for Ch3
(1 to 4095)
D 8297
Number of averaging times for Ch4
(1 to 4095)
Number of averaging times for Ch4
(1 to 4095)
Number of averaging times for Ch4
(1 to 4095)
D 8298 Error status Error status Error status
D 8299
Model code: K20 (PT), K21 (PTW) Model code: K10 Model code: K11
