Mitsubishi FX3U-4HSX-ADP User Manual

FX3U Series Programmable Controllers
User’s Manual - Hardware Edition
150
8 Installation In Enclosure
8.4 Examination for Installing Method in Enclosure
2. Example of direct installation
3. Example of combination of installation on DIN rail and direct installation
*1. FX2N-CNV-BC can be installed directly in the enclosure but cannot be installed on the DIN rail.
FX3U Series
main unit
Extension cable
• FX 0N -65EC
• FX 0N -30EC
FX 2N -CNV-BC
(+ indicates an M4 screw.)
FX 2N -
16EYT-
ESS/UL
FX 2N -
16EX-
ES/UL
1 to 2mm
(0.04" to 0.08")
1 to 2mm (0.04" to 0.08")
FX 2N-
16EX-
ES/UL
FX 2N-
10PG
FX 3U Series
main unit
DIN rail
Extension cable
• FX 0N -65EC
• FX 0N -30EC
FX 2N -CNV-BC
(+ indicates an M4 screw.)
FX 2N -
16EYT-
ESS/UL
FX 2N -
16EX-
ES/UL
1 to 2mm
(0.04" to 0.08")
1 to 2mm (0.04" to 0.08")
FX 2N-
16EX-
ES/UL
FX 2N-
10PG
*1
