FX3U Series Programmable Controllers
User’s Manual - Hardware Edition
171
9 Preparation for Wiring and Power Supply Wiring Procedures
9.2 Cable Connecting Procedures
1
Introduction
2
Features and Part Names
3
Product Introduction
4
Specifications
5
Version and Peripheral Devices
6
System Configuration
7
Input/Output Nos., Unit Nos.
8
Installation
9
Preparation and Power Supply Wiring
10
Input Wiring
In case of M3.5 terminal screw
• When one wire is connected to one terminal
• When two wires are connected to one terminal
6.8mm(0.27")
or less
3.7(0.15")
TerminalTerminal
Terminal
screw
Crimp
terminal
6.8mm(0.27")
or less
3.7(0.15")
6.8mm(0.27")
or less
3.7(0.15")
6.0mm(0.24")
or more
Terminal
screw
Crimp
terminal
Terminal
6.8mm(0.27")
or less
3.7(0.15")
6.0mm(0.24")
or more
