Mitsubishi FX3U-4HSX-ADP

FX3U Series Programmable Controllers
User’s Manual - Hardware Edition
317
16 FX2N-8/16E*-*(Input/Output Extension Blocks)
16.1 Outline
11
High-Speed Counters
12
Output Wiring
13
Wiring for Various Uses
14
Test Run, Maintenance, Troubleshooting
15
IInput/Output Powered Extension Units
16
Input/Output Extension Blocks
17
Extension Power Supply Unit
18
Other Extension Units and Options
19
Display Module
20
Terminal Block
3. For output extension
:Sink [-common], :Source [+common]
Model
Input Output
Connection
unit
Type
Number
of points
Common
system
Type
Number
of points
Common
system
Relay output type
FX 2N -8EYR-ES/UL −− − Relay 8 −
Terminal
block
FX 2N -8EYR-S-ES/UL −− − Relay 8 −
Terminal
block
FX
2N-8EYR −− − Relay 8 −
Terminal
block
FX 2N -16EYR-ES/UL −− − Relay 16 −
Terminal
block
FX
2N-16EYR −− − Relay 16 −
Terminal
block
Dedicated to sink output only
FX2N-8EYT −− −Transistor 8
Terminal
block
FX
2N-8EYT-H −− −Transistor 8
Terminal
block
FX
2N-16EYT −− −Transistor 16
Terminal
block
FX2N-16EYT-C −− −Transistor 16 Connector
FX2N-16EYS −− −Triac(SSR) 16 −
Terminal
block
Dedicated to source output only
FX 2N -8EYT-ESS/UL −− −Transistor 8
Terminal
block
FX 2N -16EYT-ESS/UL −− −Transistor 16
Terminal
block
Sink Source
Sink
Sink
Sink
Sink
Source
Source
