Mitsubishi FX3U-4HSX-ADP

FX3U Series Programmable Controllers
User’s Manual - Hardware Edition
330
16 FX2N-8/16E*-*(Input/Output Extension Blocks)
16.5 FX2N-8EX, FX2N-16EX and FX2N-16EX-C
FX2N-16EX-C
How to connect connector (FX2N-16EX-C)
80(3.15")
(mounting hole pitch)
Unit:mm (inches)
2-φ4.5 mounting holes
87(3.43")
90(3.55")
9(0.36")
40(1.58")
20
20
The terminal layout is shown in the following table
Connection face of connector
Cross section of 20-core flat cable
(Socket)
FX-16E-
CAB type cable
(Be sure to check the wire number)
B
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
A
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
24+ X7 X5X6 X4 X3 X2 X1 X0
24+ X7 X5X6 X4 X3 X2 X1 X0
Side A
Side B
Side B is for the higher input numbers,
and side A is for the lower input numbers.
(Exe.) Side B X050 to X057
Side A X040 to X047
