Mitsubishi FX3U-4HSX-ADP User Manual

FX3U Series Programmable Controllers
User's Manual - Hardware Edition
32
1 Introduction
1.2 Generic Names and Abbreviations Used in Manuals
FX2N Series special
function units
Generic name for the following models
FX2N-10GM, FX2N-20GM, FX2N-1RM(-E)-SET
FX2N Series special
function blocks
Generic name for the following models
FX2N-232IF, FX2N-16CCL-M, FX2N-32CCL, FX2N-64CL-M, FX2N-16LNK-M, FX2N-
32ASI-M, FX2N-2AD, FX2N-4AD, FX2N-8AD, FX2N-4AD-PT, FX2N-4AD-TC, FX2N-2LC,
FX2N-2DA, FX2N-4DA, FX2N-5A, FX2N-1HC, FX2N-1PG(-E), FX2N-10PG
The devices that can be added depending on the main unit to be used. For applicable
devices, refer to the User's Manual - Hardware Edition for the main unit to be used.
FX0N Series special
function blocks
Generic name for the following models
FX0N-3A
Display module
Generic name for the following models
FX3U-7DM
Memory cassettes
Generic name for the following models
FX
3U-FLROM-16, FX3U-FLROM-64, FX3U-FLROM-64L, FX3U-FLROM-1M
Battery Abbreviation of model FX
3U-32BL battery
FX Series terminal blocks
Generic name for the following models
FX-16E-TB, FX-32E-TB, FX-16EX-A1-TB, FX-16EYR-TB, FX-16EYS-TB, FX-16EYT-
TB, FX-16EYT-H-TB
The devices that can be added depending on the main unit to be used. For applicable
devices, refer to the User's Manual - Hardware Edition for the main unit to be used.
Extension cables
Generic name for the following models
FX0N-30EC, FX0N-65EC
Input/output cables
Generic name for the following models
FX-16E-500CAB-S, FX-16E-CAB, FX-16E-CAB-R, FX-A32E-CAB
150, 300 or 500 is entered in .
Connectors for input/
output
Generic name for the following models
FX2C-I/O-CON, FX2C-I/O-CON-S, FX2C-I/O-CON-SA
CC-Link master
Generic name for the following models
FX
3U-16CCL-M, FX2N-16CCL-M
Intelligent device stations Abbreviation of FX3U-64CCL interface block
Remote I/O stations Remote stations that handle information in bit units only
Remote device stations Abbreviation of FX2N-32CCL interface block
Remote stations Generic name for remote I/O stations and remote device stations
Power supply adapter Unit to be connected to supply power to the CC-Link/LT system
Dedicated power supply Power supply to be connected to supply power to the CC-Link/LT system
AS-i master Abbreviation of model FX
2N-32ASI-M AS-i system master block
Peripheral devices
Generic name for programming software, handy programming panel (HPP) and indicator
Programming tool Generic name for programming software and handy programming panel (HPP)
Programming software Generic name for GX Works2, GX Developer and FX-PCS/WIN (-E)
GX Works2
Abbreviation of programming software packages SWDNC-GXW2-J and SWDNC-
GXW2-E
GX Developer
Abbreviation of programming software packages SWD5C-GPPW-J and SWD5C-
GPPW-E
FX-PCS/WIN (-E) Abbreviation of programming software packages FX-PCS/WIN and FX-PCS/WIN-E
Handy programming
panels (HPP)
Generic name for the following models
FX-30P, FX-20P(-E)-SET0, FX-20P(-E), FX-10P-SET0, FX-10P(-E)
USB/RS-422 converters Abbreviation of FX-USB-AW
RS-232C/RS-422
converters
Generic name for the following models
FX-232AW, FX-232AWC, FX-232AWC-H
RS-232C/RS-485
converters
Abbreviation of FX-485PC-IF
Indicators
GOT1000 Series Generic name for GT15, GT11 and GT10
GOT-900 Series Generic name for GOT-A900 Series and GOT-F900 Series
GOT-A900 Series Generic name for GOT-A900 Series
GOT-F900 Series Generic name for GOT-F900 Series
Abbreviation/
generic name
Description
