Mitsubishi FX3U-4HSX-ADP User Manual

FX3U Series Programmable Controllers
User’s Manual - Hardware Edition
477
A Operation of Special Devices (M8000 -, D8000 -)
A-1 Special Auxiliary Relay (M8000 to M8511)
21
Memory Cassette
22
Battery
A
Special Devices (M8000-,D8000-)
B
Instruction List
C
Character-code
D
Discontinued models
E
Precautions for battery transportation
F
Handling of batteries in EU member states
N:N Network
[M]8180
Not used
–
[M]8181 –
[M]8182 –
[M]8183
Data communication error
(Master station)
D8201 to
D8218
[M]8184
Data communication error
(Slave station No.1)
[M]8185
Data communication error
(Slave station No.2)
[M]8186
Data communication error
(Slave station No.3)
[M]8187
Data communication error
(Slave station No.4)
[M]8188
Data communication error
(Slave station No.5)
[M]8189
Data communication error
(Slave station No.6)
[M]8190
Data communication error
(Slave station No.7)
[M]8191 Data communication in execution
[M]8192
Not used
–
[M]8193 –
[M]8194 –
[M]8195 –
[M]8196 –
[M]8197 –
High-Speed Counter Edge Count Specification
M 8198
*1*2
C251, C252, C254: 1/4 edge count
selector
–
M 8199
*1*2
C253, C255, or C253 (OP): 1/4
edge count selector
–
*1. OFF: 1 edge count
ON: 4 edge count
*2. Cleared when PLC switches from RUN to STOP.
Number and
name
Operation and function
Correspond-
ing special
device
Counter Up/down Counter Counting Direction
M 8200 C200
When M8 is ON, the
corresponding C is
changed to down mode.
• ON: Down count operation
• OFF: Up count operation
–
M 8201 C201 –
M 8202 C202 –
M 8203 C203 –
M 8204 C204 –
M 8205 C205 –
M 8206 C206 –
M 8207 C207 –
M 8208 C208 –
M 8209 C209 –
M 8210 C210 –
M 8211 C211 –
M 8212 C212 –
M 8213 C213 –
M 8214 C214 –
M 8215 C215 –
M 8216 C216 –
M 8217 C217 –
M 8218 C218 –
M 8219 C219 –
M 8220 C220 –
M 8221 C221 –
M 8222 C222 –
M 8223 C223 –
M 8224 C224 –
M 8225 C225 –
M 8226 C226 –
M 8227 C227 –
M 8228 C228 –
M 8229 C229 –
M 8230 C230 –
M 8231 C231 –
M 8232 C232 –
M 8233 C233 –
M 8234 C234 –
High-Speed Counter Up/down Counter Counting Direction
M 8235 C235
When M8 is ON, the
corresponding C is
changed to down mode.
• ON: Down count operation
• OFF: Up count operation
–
M 8236 C236 –
M 8237 C237 –
M 8238 C238 –
M 8239 C239 –
M 8240 C240 –
M 8241 C241 –
M 8242 C242 –
M 8243 C243 –
M 8244 C244 –
M 8245 C245 –
Number and
name
Operation and function
Correspond-
ing special
device
