FX3U Series Programmable Controllers
User’s Manual - Hardware Edition
Revised History
3/2007 D • Tightening Torque at the Time of Loading /Unloading System Terminal Block
Anchoring, Notice Addition (Subsection 2.2.1, 8.5.4, 9.1.2 and 15.2.2).
• Life Details Addition of Relay Output Contact (Subsection 4.4.2, 12.2.2, 14.4.3 and
20.7.5).
• Caution Addition (Section 6.1) for Extension-Equipment Selection.
• Caution Addition for Time of Wiring (Subsection 12.2.4 and 20.7.4)
• Various Corrections and Table Additions (Subsection 14.4.2 and 22.3.1) for the
Service Life of the Battery.
• Notice Addition at the Time of Battery Replacement (Subsection 22.5)
• Production Stop Addition (Appendix D)
6/2007 E • Explanation corrections for reading the battery's year/month of manufacture.
11/2008 F Errors are corrected.
11/2009 G • The following products are added:
- Special function blocks
FX
3U-64CCL
Contents are added to product introduction (Chapter 3), examination of system
configuration (Chapter 6), installation in enclosure (Chapter 8), other extension
devices (Chapter 18), etc.
- Special adapters
FX
3U-3A-ADP, FX3U-4AD-PTW-ADP, FX3U-4AD-PNK-ADP, FX3U-CF-ADP
Contents are added to product introduction (Chapter 3), examination of system
configuration (Chapter 6), installation in enclosure (Chapter 8), other extension
devices (Chapter 18), etc.
- Programming tool
FX-30P
Contents are added to programming tool applicability (Section 5.2), etc.
• Ver. 2.41 is supported.
- The baud rate "38400 bps" is supported in RS and RS2 instructions, inverter
communication and computer link.
• Ver. 2.61 is supported.
- Supports FX
3U-CF-ADP
Six types of instructions are added (Appendix B-1)
For the details of these instructions, refer to the FX3U-CF-ADP user’s manual.
Special auxiliary relays and special data registers are added (Appendix A)
- Supports FX3U-3A-ADP
Special auxiliary relays and special data registers are added (Appendix A)
- Customer keyword / permanent PLC lock is supported.
• Cautions on connecting peripheral equipment by way expansion board or special
adapter are added (Subsection 5.2.4)
• The applicability of other peripheral equipment is added (Section 5.5)
• Precautions for Battery Transportation are added (Appendix E)
• Handling of Batteries and Devices with Built-in Batteries in EU Member States are
added (Appendix F)
• Errors are corrected.
3/2010 H • Explanation corrections for manufacturer's serial number and lot number.
• Explanation corrections for battery's lot number.
