FX3U Series Programmable Controllers
User’s Manual - Hardware Edition
44
3 Introduction of Products (Compliant with Overseas Standards)
3.1 List of Products (to be Connected) and Interpretation of Model Names
3. Pulse output and positioning
 : Compliance with standard or self-declaration  : Not targeted − : Not applicable
→ For more information on CE, UL and cUL, refer to Page 15 or later.
*1. Up to 3 units can be connected to one system. Connect them to the end of the system. For details,
refer to FX2N-1RM(-E)-SET Handy Manual.
*2. Please consult with Mitsubishi Electric for information on marine standard practices and the
corresponding types of equipment.
*3. Products manufactured in and after June, 2006 will comply with the UL and cUL standards.
4. Data link and communication functions
 : Compliance with standard or self-declaration  : Not targeted − : Not applicable
* Please consult with Mitsubishi Electric for information on marine standard practices and the
corresponding types of equipment.
→ For more information on CE, UL and cUL, refer to Page 15 or later.
Model name Description
CE
UL
cUL
Marine
EMC LVD
FX2N-1PG
Pulse output for independent 1-axis control (manual in
Japanese supplied) [100 kHz open collector output]
− − − −
FX2N-1PG-E
Pulse output for independent 1-axis control (manual in
English supplied) [100 kHz open collector output]
*2
FX
2N-10PG
Pulse output for independent 1-axis control
[1 MHz differential line driver output]
 −
FX3U-20SSC-H
Simultaneous 2-axis (independent 2-axis) control
[Applicable to SSCNET III]


*3
−
FX2N-10GM
Pulse output for independent 1-axis control
[200 kHz open collector output]
 −
FX
2N-20GM
Pulse output for simultaneous 2-axis (independent 2-
axis) control [200 kHz open collector output]
 −
FX
2N-1RM-SET
*1
1-axis programmable cam switch (manual in Japanese
supplied)
− − − −
FX2N-1RM-E-SET
*1
1-axis programmable cam switch (manual in English
supplied)
 − *2
Number of
connected units
Number of input/output
points occupied
Count of number of connected special
function units/blocks
1 unit
8 points 12 units
3 units
Model name Description
CE
UL
cUL
Marine
EMC LVD
FX2N-232IF 1-ch RS-232C non-protocol communication  − *
FX3U-16CCL-M
Master for CC-Link (Compatible with Ver. 2.00 and
Ver. 1.10)
Connectable stations:Remote I/O station,
Remote device station,
Intelligent device station
 −
FX2N-16CCL-M
Master for CC-Link (Compatible with Ver. 1.10)
Connectable stations:Remote I/O station,
Remote device station
 −−
FX3U-64CCL
CC-Link interface (Intelligent device station)
[1 to 4 stations occupied]
 −
FX
2N-32CCL
CC-Link interface (Remote device station)
[1 to 4 stations occupied]
 −−
FX2N-64CL-M Master for CC-Link/LT  −
FX2N-16LNK-M Master for MELSEC I/O Link  −
FX2N-32ASI-M Master for AS-i system  −−
D
E
D
D
D
D
E
E
E
E
D
