Morgana DocuMaster MFC - Service Manual 159
4. Service Procedures - Replace Components - Creaser Module
4
Before you start:
• Remove the creaser module (See Section 4.10.1)
• Remove the LH side plate (See Section 4.10.2.2).
Step Action Information
1 Disengage the quadrant assembly
from the DynaTilt motor gear.
Rotate the motor gear clockwise until
the quadrant is disengaged from the
motor gear.
2 Remove the DynaTilt motor gear.
• Loosen the two set screws that
attach the DynaTilt motor gear to
the DynaTilt motor shaft.
• Pull the motor gear off the
DynaTilt motor shaft.
3 Cut the cable ties that attach the
DynaTilt motor cable to the other
cables.
4 Disconnect the DynaTilt motor
cable co
nnector from the LH side
plate.
Push in the latches on the two sides
of the cable connector, and pull the
cable away from the side plate.
5 Remove the DynaTilt Motor. Remove the four screws that attach
the DynaT
ilt motor to the LH side
plate.
Note: The screws are att
ached to the
motor retention-plate.
6 Attach the replacement DynaTilt
mot
or.
Install the four screws that attach the
DynaTilt motor to the LH side plate,
but do not tighten them fully.
7 Attach the DynaTilt motor gear to
the D
ynaTilt motor shaft.
• Put the DynaTilt motor gear on to
the DynaTilt motor shaft.
• Engage the quadrant assembly
with the DynaTilt motor gear.
• Position the DynaTilt motor gear
so that it is aligned centrally with
the quadrant assembly.
• Tighten the two set screws that
attach the DynaTilt motor gear to
the DynaTilt motor shaft (make
sure that one of the screws is
tightened against the flat on the
DynaTilt motor shaft).
8 Attach the LH side plate. (See Section 4.10.2.2).
9 Do a check of the DynaTilt motor
gear
play and adjust as necessary.
(See Section 4.5.15.1).
