4. Service Procedures - Replace Components - Creaser Module
166 Morgana DocuMaster MFC - Service Manual
Before you start:
• Remove the GUI Panel (See Section 4.7.4).
Step Action Information
1 Remove the transfer chain (See Section 4.10.1.1).
2 Disconnect the two wires from the
terminals
on the DynaTilt Home
Switch.
3 Remove the DynaTilt home switch.
• Remove the two screws that
attach the DynaTilt home switch
to the mounting lever.
• Lift the DynaTilt home switch off
the mounting lever.
4 Attach the replacement DynaTilt
home switch.
5 Do a check of the DynaTilt home
switch limit position
and adjust as
necessary.
(See Section 4.5.16.1).
4.10.13 Replace the Creaser Blade Out Switch
The MFC control software does not support the blade-out switch function.
