MTE PTS 400.3 PLUS - Save Continuous Measurements

PTS 400.3 PLUS Operation Manual_R02 Page 192/306
10.2.3 Save continuous measurements
1
Call storage of results menu
2
Load / edit administrative data (optional)
3
Call save results and exit to define a result file
The file selection menu [6.1] is called with the directory Any Test Results displayed.
Create result file, as described under save single measurement step 5.
The continuous storage mode is automatically started, when the file selection menu is left with
the exit door FB. The calling measurement menu is displayed again.
Status indications
The camera FB is shown depressed during continuous saving is active.
The compact flash status indication changes periodically to the save continuous
symbol.
3
Run measurement
The measurement results are cyclically saved according to the defined saving mode (event or
time interval).
4
Select camera FB and press enter to stop continuous saving.
The data saving is stopped.
Status indications
The camera FB is shown normal again.
The save continuous symbol disappears and the normal compact flash status in-
dication is displayed again.
5
Call storage of results menu and preview results (optional)
The last saved measurement results are shown. With the preview function, only one of the
saved result sets can be viewed. To see all the saved results the data must be transferred to
CALegration.
6
Exit, back to calling measurement menu
