Load point data
Load point data menu
Object files for load point data can be loaded. The
file names of the actual loaded object files are
shown at:
Load point dataset
Harmonics
RCS Ripple Control telegram type dataset
RCS Ripple Control Sequence dataset
6.7.1 Load point dataset
Indications / settings
Load / edit object file
The file selection menu [6.1] is called with the object file directory:
Load point Selections
For description of Load point dataset see [7.2.1]
6.7.2 Harmonics dataset
Load / edit object file
The file selection menu [6.1] is called with the object file directory:
Harmonics Selections
For description of Harmonics dataset see [7.3.1]
6.7.3 Ripple control RCS telegram type dataset
Load / edit object file
The file selection menu [6.1] is called with the object file directory:
RSC Param Selections
For description of RCS Ripple Control parameter type dataset see [7.4.2]
6.7.4 Ripple control RC Sequence dataset
Load / edit object file
The file selection menu [6.1] is called with the object file directory:
RCS Telegram Selections
For description of RC Sequence Telegrams dataset see [7.4.1]
