PTS 400.3 PLUS Operation Manual_R02 Page 87/306
7.2.2 Additional information to the network types
Settings of voltage U depending on network type
Warning!
Check the settings for the voltage. Dangerous high voltage can destroy your
meter under test!
The input field will be selected automatically depending on the selected network type.
The input fields for the settings of voltage can be related to the phase-phase voltage U
LL
or the phase-neutral voltage U
LN
.
3P4WY
3P3W
1P2W
1P3W
2P3W
3P4WΔ
Custom
Settings input in Load point UIφf menu
U
LN
X
X
X
X
U
LL
X
X
X
U
100V
230V
240V
120V
240V
U1
230V
240V
U2
230V
120V
240V
U3
230V
240V
Settings of source in load point menu
U1
230V
57.7V
0V
120V
120V
120V
240V
U2
230V
57.7V
0V
120V
120V
120V
240V
U3
230V
57.7V
230V
0V
0V
207V
240V
Settings for 1P2W mode
Warning!
In this mode voltage output U
3
and current output I
3
will be used.
