Transformer data
Transformer data menu
Object files for current CT and potential PT types
and CT / PT transformers can be loaded. The file
names of the actual loaded object files are shown
at:
Current transformer CT type dataset
Current transformer CT dataset
Potential transformer PT type dataset
Potential transformer PT dataset
Load / edit object file
The file selection menu [6.1] is called with the object file directory:
CT Type Selections
For description of actual current transformer CT type see [6.6.1]
Load / edit object file
The file selection menu [6.1] is called with the object file directory:
CT Selections
For description of actual current transformer CT dataset see [6.6.2]
Load / edit object file
The file selection menu [6.1] is called with the object file directory:
PT Type Selections
For description of actual potential transformer PT type dataset see [6.6.3]
Load / edit object file
The file selection menu [6.1] is called with the object file directory:
PT Selections
For description of actual potential transformer PT dataset see [6.6.4]
