PTS 400.3 PLUS Operation Manual_R02 Page 94/306
Edit ripple control frequency
Input of the ripple control frequency in Hz.
Input of text with up to 64 characters.
Exit and accept settings, back to calling menu.
Warning!
Check all connections in the test circuit.
Check the settings UmaxImax.
Check the settings UIφf.
Check if the interrupt button on the top of the power source PPS 400.3 is free
accessible.
Interrupt button on PPS 400.3
Warning!
Use the interrupt button on the power source PPS 400.3 in case of emer-
gency, push down the button when needed.
The interrupt button on the power source PPS 400.3 will interrupt the supply
to the PPS 400.3. The output signals will be stopped immediately. After re-
leasing the interrupt button the PPS 400.3 wil be supplied with power again.
The output signals of the power source are still switched off after releasing
the interrupt button.
The output signals of the power source will be stopped immediately by
pushing the FB Fast Stop.
