PTS 400.3 PLUS Operation Manual_R02 Page 76/306
The number of active input fields is depending on the connection mode defined in the
loaded meter type. E.g. at 3-wire mode only 2 input fields are active.
Load / enter metering code
The file selection menu [6.1] is called with the object file directory:
Metering code Selections
Call Load object file to load a saved metering code. The meter data set
menu is displayed again and the loaded metering code is displayed.
Call edit actual object or create new object to call the actual meter
code dataset menu.
Actual meter code dataset
Enter or modify directly with virtual or
external keyboard:
Exit, back to calling menu
Exit file selection menu, back to meter dataset menu. The entered metering
code is displayed.
Exit, save actual settings, back to calling menu
