Unbalance graph view
Example: Analysis of recorded unbalance of 1 week
Unbalance table view
Example: Analysis of recorded unbalance of 1 week
Graph  Table
View
Back to PQ Online menu
Exit
Zero sequence (U0/U1), Negative sequence (U2/U1)
Selection of unbalance factors
Load/Save Settings
Zero sequence (U0/U1), Negative sequence (U2/U1)
Table  Graph
View
0/Max  Min/Max
Vertical scale
Back to calling menu
Exit
Selection of unbalance factors
24 h within 7 days
Time interval of graph window
U2/U1 = 2 % regarding EN 50160
Evaluation limit
Load/Save Settings
