MultiSmart Installation & Operation Manual
After the source is selected, press Back, and repeat the process for each digital output. The sources listed in
this setup screen include:
Any Fault Probe 1 Sensor Fault All Pumps Unavailable DC Over Voltage
Remote Source Probe 2 Sensor Fault Any Pump Faulted DC Under Voltage
High High Level Alarm Pump 1 Call to Run All Pumps Faulted Battery Over Voltage
High Level Alarm -etc to number of pumps Pump 1 Off Battery Under Voltage
Low Level Alarm Pump 1 Reversing -etc to number of pumps Test Battery
Low Low Level Alarm -etc to number of pumps Pump 1 Off or Unavailable Application Failure*
Any Level Alarm Any Pumps Running -etc to number of pumps Modem Reboot
Any High Level Alarm All Pumps Running Any Pumps Off AIN1 Over Range
Any Low Level Alarm No Pumps Running All Pumps Off AIN1 Under Range
Primary Level Fault Pump 1 Unavailable
Any Pumps Off or
Unavailable
AIN2 Over Range
Backup Level Fault -etc to number of pumps
All Pumps Off or
Unavailable
AIN2 Under Range
Well Mixer Active All Pumps Available Over Voltage
Well Washer Active Any Pumps Unavailable Under Voltage
Table 17 – Digital Output Sources
*Application failure is the internal watchdog functionality.
If the desired source cannot be found in this list, press the Advanced button, which then displays the Tag
Browser and allows the selection of any digital tag within the system.
Page 132 of 260 MultiSmart_IO_Manual_R20
