14.6 Advanced Analog Input Options
Name Description Range/Type
Delay (ms) This delay is used as a low pass filter. 0 - 100000ms
Description
Description of the input. This is the same item as the one
shown on the General IO Module Configuration Screen.
Text
Enable Over Range? Sets whether the Over Range feature is enabled or disabled. True / False
Enable Under Range? Sets whether the Under Range feature is enabled or disabled. True / False
Over Range Delay (sees)
The time to wait after the Over Range Set Point has been
reached before an over range event is generated.
0 -120s
Over Range Set Point (%) This is the set point for over range detection. 0 -100%
Under Range Delay (sec)
The time to wait after the Under Range Set Point has been
reached before an under range event is generated.
0 -120s
Under Range Set Point (%) This is the set point for under range detection. 0 - 100%
Value
This sets advanced parameters affecting the value produced
by the analog input. These include:
Deadband
Raw Max
Raw Min
Scaled Max
Scaled Min
Table 11 – Advanced Analog Input Options
14.7 External Digital & Analog Modules
If an I/O unit has Modbus or DNP3 capabilities, then a MultiSmart unit can be configured to communicate to
the device. The configuration will usually require custom engineering, increasing the effort required for
integration.
To speed up this process, certain I/O units have been selected as standard MultiSmart solutions. MultiSmart
has wizard functionality which can be used to greatly simplify configuration. Once configured, these analog
inputs, digital outputs and digital inputs are listed in the respective LCD screen menus wherever the
corresponding MultiSmart I/Os are displayed. Hence they can be assigned to any faults or configured to use
with other functionality in the unit using the same procedure as that for native MultiSmart I/O.
Currently, this wizard functionality supports the following units:
• ADAM-4017+ - RS485, 8 x AIN
• ADAM-4051 - RS485, 16 DIN
• ADAM-6017 - Ethernet, 8 x AIN, 2 x DOT
• ADAM-6050 - Ethernet, 12 x DIN, 6 x DOT
• ADAM-6051 - Ethernet, 12 x DIN, 2 x DOT
• ACROMAG-961 - Ethernet, 6 DC Current Input Channels (6 x AIN)
• ACROMAG-983 - Ethernet, 12 Discrete Input Output Channels
Page 104 of 260 MultiSmart_IO_Manual_R20
