MultiSmart Installation & Operation Manual
7.2 Default Wiring Setup for Pump Control Board
While many different configurations of the MultiSmart are possible, five common configurations are illustrated
in this section. These default configurations can be applied by completing the Setup Wizard in the Settings
menu. After a default configuration has been applied, changes can be made as required. Refer to Section
7.3 for a complete description of the Pump Control I/O Board.
7.2.1 Default 1 – 10 Sensor Probe and 2 Pumps
Figure 34 – Default 1
MultiSmart_IO_Manual_R20 Page 39 of 260
