MultiSmart Installation & Operation Manual
19.4.1 Log Type / Pump Filters
Within this filter, the first option is Log Type with a selection between different logging methods (described
earlier in this chapter):
• Faults and Events
• Interval Logs
• Crisis Logs
• Config Logs
These different logs cannot be displayed together. Additional to Log Type there are check boxes for:
• Events
• Faults
• Pump 1
• Pump 2 etc
To only view faults, uncheck the Events box. To remove faults from the view, uncheck the Faults box. To
view station data not relating to a pump, uncheck both (or all) the pump boxes.
Once changes are made, press Save, then Back -> Back and the History screen will now show the filtered
data.
19.4.2 General Event Filters
There are 17 useful filters:
Table 33 – Predefined Filters Available in General Filters
By default, all of these filters are enabled (checked). To remove any from the history view simply uncheck the
box.
19.4.3 Include Filters and Exclude Filters
This simply allows text strings to be filtered in or out.
For example, to find any “Energy” related information, go to the Include Filter, enter the text string “Energy”
and press Add Filter. Then press Save, Back and Back, now the history page will only show logged data
with the text “Energy”,
e.g. Pump 1 Energy, Pump 2 Energy.
The Exclude Filter does the opposite and both can be used together if necessary – even though this would
be an unusual requirement.
MultiSmart_IO_Manual_R20 Page 169 of 260
