MultiSmart Installation & Operation Manual
24.3.2.8 ReadBoolSetPoint
This function block can be used to read the value of Digital, Digital Control, and Boolean Attribute tags. It
receives the full name of the tag as an input. It then returns a Boolean result indicating whether the operation
was successful, together with the value of the selected tag.
24.3.2.9 ReadBoolValue
This function block can be used to read the value of Digital, Digital Control, and Boolean Attribute tags. It
receives the full name of the tag as an input. It then returns a Boolean result indicating whether the operation
was successful, together with the value of the selected tag.
24.3.2.10 ReadFlag
This function block returns the status flags of a tag. Flags are comprised of combinations of bits, with the
following interpretations (values below are hexadecimal numbers):
24.3.2.11 ReadFloatSetPoint
This function block can be used to read the set point of Analog Control and Fixed-Point Attribute tags. It
receives the full name of the tag as an input. It then returns a Boolean result, indicating whether the
operation was successful, together with the set point of the selected tag.
24.3.2.12 ReadFloatValue
This function block can be used to read the value of Analog, Analog Control, Fixed-Point, and Fixed-Point
Attribute tags. It receives the full name of the tag as an input. It then returns a Boolean result, indicating
whether the operation was successful, together with the value of the selected tag.
24.3.2.13 ReadIntegerSetPoint
This function block can be used to read the set point of Integer Attribute tags. It receives the full name of the
tag as an input. It then returns a Boolean result, indicating whether the operation was successful, together
with the set point of the selected tag.
Page 210 of 260 MultiSmart_IO_Manual_R20
