128 User Manual Version 3.1
Pos: 84.6 /Bedienungsan leitungen/Geräte s pezifisch/Druc ker/Monitor Messages/M 06_EPROM Unexpected addres s S0 @ 2\mod_12719412491 82_912.doc @ 16853 @
No. Message Cause
M06 MONITOR-ERROR: M06
UNEXPECTED ADDRESS
xxxxxxxxx
While data transferring a faulty
address range was detected in
record S0
Elimination
• Check hex file
Pos: 84.7 /Bedienungsan leitungen/Geräte s pezifisch/Druc ker/Monitor Messages/M 07_EPROM Image too large @ 2\ mod_1271941734242_912. doc @ 16857 @
No. Message Cause
M07 MONITOR-ERROR: M07
IMAGE TOO LARGE
Hex file size too large
Elimination
• Check hex file
Pos: 84.8 /Bedienungsan leitungen/Geräte s pezifisch/Druc ker/Monitor Messages/M 08_EPROM Record S3 Checksu m Error @ 2\mod_127194184497 5_912.doc @ 16891 @
No. Message Cause
M08 MONITOR-ERROR: M08
S3 FAULT CHECKSUM
ADR: xxxxxxxx
Checksum of record S3 is faulty
Elimination
• Transfer the hex file again
• Check if hex file is correct
• When error still occurs call
service
Pos: 84.9 /Bedienungsan leitungen/Geräte s pezifisch/Druc ker/Monitor Messages/M 09_EPROM Unexpected addres s S3 @ 2\mod_12719419235 53_912.doc @ 16895 @
No. Message Cause
M09 MONITOR-ERROR: M09
UNEXPECTED ADDRESS
xxxxxxxxx
While data transferring a faulty
address range was detected in
record S3
Elimination
• Check hex file
Pos: 84.10 /Bedienungsan leitungen/Gerät e spezifisch/Dr ucker/Monitor Messages/ M10_Checksum error flash S7 @ 2\mod_127194199244 3_912.doc @ 16899 @
No. Message Cause
M10 MONITOR-ERROR: M10
S7 FAULT: xxxxxxxx
CHKSUM:ssss-ssss
Wrong checksum of hex file
Elimination
• Transfer the hex file again • When error still occurs call
service
Pos: 84.11 /Bedienungsan leitungen/Gerät e spezifisch/Druc ker/Monitor Messages/ M11_EPROM Image too large @ 2\ mod_1271942098442_912. doc @ 16903 @
