70 User Manual Version 3.1
Brake
In this test the brake of the paper transport continuously switches its state between “on”
and “off”.
To proof the brakes functionality, the user has to turn the paper transport roll by hand.
When the status is “on” the roll should be blocked.
Pos: 61.98 /Bedienungsan leitungen/Gerät e spezifisch/Druc ker/Menüpunkte Druc ker/Ü3/Ü4/Ü3_3217_Sof t Brake @ 1\mod_12556839959 12_912.doc @ 6639 @
Soft Brake
This test checks the soft brake function of the printer.
Pos: 61.99 /Bedienungsan leitungen/Gerät e spezifisch/Druc ker/Menüpunkte Druc ker/Ü3/Ü4/Ü3_3218_C lutch /Brake/Run @ 1\mod_12 55683998261_912.doc @ 6643 @
Clutch /Brake/Run
The printer will start the transport and test the clutch and the brake.
Pos: 61.100 /Bedienungsa nleitungen/Gerä te spezifisch/D rucker/Menüpunkte Druc ker/Ü3/Ü4/Ü3_3219_Paper Sensor @ 0\mod_12549160945 77_912.doc @ 5067 @
Paper Sensor
This feature is used to check the status of the paper sensor (top of form sensor).
Status Note
Sensor is free
The sensor detects no material.
Sensor is not free
The sensor detects material.
Pos: 61.101 /Bedienungsa nleitungen/Gerä te spezifisch/D rucker/Menüpunkte Druc ker/Ü3/Ü4/Ü3_3227_Tes t Continuous @ 0\mod_1254 917241934_912.doc @ 5123 @
Test Continuous
The printer will move the cartridge carriage and the material transport continuously.
Pos: 61.102 /Bedienungsa nleitungen/Gerä te spezifisch/D rucker/Menüpunkte Druc ker/Ü3/Ü4/Ü3_3228_R oller Cleaning @ 0\mod_125490 8128497_912.doc @ 4693 @
Roller Cleaning
When activating this function, the feed roll of the printer will start to turn. The user can
clean the roller, by carefully pressing a damp cloth against the rotating roll.
Attention
Don’t let a piece of cloth get into the printer. Watch your hands!
Read the description for Cleaning and Service in the user manual.
Pos: 61.103 /Bedienungsa nleitungen/Gerä te spezifisch/D rucker/Menüpunkte Druc ker/Ü3/Ü4/Ü3_3234a_C artridge_Shuttleh ead_AS-700/AS- 710 @ 3\mod_1279784189938_91 2.doc @ 24063 @
