Neopost AS-710 - Figure 2:Overview Rear Side

User Manual Version 3.1 17
Figure 2:Overview rear side
10 USB 2.0 interface to the PC for
sending print data
13 On/off switch
11 Serial interface to the PC for status
feedbacks and service purposes
14 Power input module
12 Ethernet (TCP/IP) interface for
sending print data
15 Fixing knobs for paper side guides
and ramp
15
10
11
12
13
14
