Cleaning the
contacts
• Dampen the cleaning cloth with a small amount of alcohol.
• Do NOT bring the alcohol in contact with the nozzle plate (see
Figure 51)!
• Carefully wipe the contacts with the cloth.
• Check if all contacts are free of ink stains. If not, continue wiping
the contacts until all are shiny and stain free.
• Optional: To check if all contacts are completely clean, use the
following menu: SERVICE > HARDWARE TEST > Cartridge. If this
test shows MISSING DOTS: no for each cartridge, the contacts are
completely clean. For a more detailed description of the menu
refer to the section Fehler! Verweisquelle konnte nicht
gefunden werden., on page Fehler! Textmarke nicht
definiert. of this manual.
Figure 50: Cleaning the nozzle plate Figure 51: Nozzle plate and contacts
Pos: 66 /Bedienungsanlei tungen/Geräte spezi fisch/Druc ker/8.1.x_Ü3_Cleaning_t he_pen_board_con tacts @ 2\mod_1265722269294 _912.doc @ 11770 @ 3
Nozzle plate
Contacts
