Neopost AS-710 - Figure 3: Overview Frontside with Open Cover

18 User Manual Version 3.1
Figure 3: Overview frontside with open cover
7 Transparent saftey cover (open) 19 Cartridge carriage (shuttle)
17 Ink cartridge 20 Wiper for ink cartridge
(part of the service station)
18 Capping for ink cartridge
(part of the service station)
21 Movable exit rollers
