S350 Series 24-Port (PoE+) and 48-Port Gigabit Ethernet Smart Managed Pro Switches
Configure Switching User Manual174
7. Configure the following settings:
• VLAN ID. The VLAN ID for which the IGMP snooping querier must be enabled. Y
ou
can select an existing VLAN only.
• Querier Election Participate Mode. Enable or disable the querier mode:
- Disable. Upon seeing another querier of the same version in the VLAN, the
snooping querier moves to the non-querier state.
- Enable.
The snooping querier participates in querier election, in which the lowest
IP address operates as the querier in that VLAN. The other querier moves to
non-querier state.
• Snooping Querier VLAN Address. Specify the snooping querier IP address to be
used as the source address in periodic IGMP queries that are sent to the VLAN.
8. Click the Apply button.
Your settings are saved.
Display IGMP Snooping Querier for VLAN Status
To display querier VLAN status:
1. Connect your computer to the same network as the switch.
You can use a WiFi or wired connection to connect your computer to the network, or
connect directly to a switch that is off-network using an Ethernet cable.
2. Launch a web browser.
3. In the address field of your web browser, enter the IP address of the switch.
If you do not know the IP address of the switch, see
Discover or Change the Switch IP
Address on page 12.
The login window opens.
4. Enter the switch’s password in the Password field.
The default password is
password.
The System Information page displays.
5. Select Switching> Multicast > IGMP Snooping Querier > Querier VLAN Status.
6. To refresh the page with the latest information about the switch, click the Refresh button.
