the tag. In an untagged frame, the VLAN is the port VLAN ID specified for the port that
received this frame.
• Disable. All frames are forwarded in accordance with the 802.1Q VLAN bridge
specification. The default is Disable.
13. In the
Port Priority field, specify the default 802.1p priority assigned to untagged packets
arriving at the port.
You can enter a number from 0 to 7.
14. Click the Apply button.
Your settings are saved.
The following table describes the nonconfigurable fields.
Table 31. Nonconfigurable fields on the PVID Configuration page
Field Description
Current Ingress Filtering Indicates whether ingress filtering is enabled for the interface.
Untagged VLANs The number of untagged VLANs for the interface.
Tagged VLANs The number of tagged VLANs for the interface.
Forbidden VLANs The number of forbidden VLANs for the interface.
Dynamic VLANs The number of dynamically added VLANs for the interface.
Configure a MAC-Based VLAN
The MAC-Based VLAN feature allows incoming untagged packets to be assigned to a VLAN
and thus classify traffic based on the source MAC address of the packet.
You define a MAC-to-VLAN mapping by configuring an entry in the MAC-to-VLAN table. An
entry is specified through a source MAC address and a VLAN ID. The MAC-to-VLAN
configurations are shared across all ports of the switch (that is, a system-wide table exists
with MAC address–to–VLAN ID mappings).
When untagged or priority-tagged packets arrive at the switch and entries exist in the
MAC-to-VLAN table, the source MAC address of the packet is looked up. If an entry is found,
the corresponding VLAN ID is assigned to the packet. If the packet is already priority-tagged,
it maintains this value. Otherwise, the priority is set to zero.
The assigned VLAN ID is verified
against the VLAN table. If the VLAN is valid, ingress processing on the packet continues.
Otherwise, the packet is dropped. This implies that you can configure a MAC address
mapping to a VLAN that you did not yet create on the switch.

NETGEAR GS324T Specifications

General

Switch type	Managed
Switch layer	L2/L3/L4
ARP inspection	Yes
Master (outer) case width	270 mm
Master (outer) case height	271 mm
Master (outer) case length	481 mm
Master (outer) case weight	8850 g
Harmonized System (HS) code	85176990
Quantity per master (outer) case	3 pc(s)
Package type	Box
Package depth	465 mm
Package width	229 mm
Package height	79 mm
Package weight	2710 g
Cables included	AC
Stackable	-
Product color	Black
Input current	5 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	13.5 W
Operating temperature (T-T)	0 - 40 °C
MAC address table	16000 entries
Power connector	AC-in jack
SFP module slots quantity	2
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Number of VLANs	256
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3az, IEEE 802.3x
Virtual LAN features	Private VLAN, Voice VLAN, Port-based VLAN
DHCP features	DHCP client

Weight and Dimensions

Depth	169 mm
Width	328 mm
Height	43 mm
Weight	1620 g
