S350 Series 24-Port (PoE+) and 48-Port Gigabit Ethernet Smart Managed Pro Switches
Manage Device Security User Manual289
6. From the ACL ID menu, select the ACL that includes the rule that you want to modify.
7. In the Extended ACL Rule
Table, click the rule.
The rule is a hyperlink. The Extended ACL Rule Configuration page displays.
8. Modify the extended IP ACL rule criteria.
9. Click the Apply
button.
Your settings are saved.
Delete an Extended IP ACL Rule
To delete an extended IP ACL rule:
1. Connect your computer to the same network as the switch.
You can use a WiFi or wired connection to connect your computer to the network, or
connect directly to a switch that is off-network using an Ethernet cable.
2. Launch a web browser.
3. In the address field of your web browser, enter the IP address of the switch.
If you do not know the IP address of the switch, see
Discover or Change the Switch IP
Address on page 12.
The login window opens.
4. Enter the switch’s password in the Password
field.
The default password is password.
The System Information page displays.
5. Select Security >
ACL >
Advanced > IP Extended Rules.
The IP Rules page displays.
6. From the ACL ID menu, select the ACL that includes the rule that you want to delete.
7. In the
Extended ACL Rule
Table, select the check box that is associated with the rule.
8. Click the Delete button.
The rule is removed.
Configure IP ACL Interface Bindings
When you bind an IP ACL to an interface, all the rules that you defined for the IP ACL are
applied to the selected interface.
If resources on the switch are insufficient, an attempt to bind an ACL to an interface fails.
