S350 Series 24-Port (PoE+) and 48-Port Gigabit Ethernet Smart Managed Pro Switches
Manage Device Security User Manual278
Delete an IP ACL
To delete an IP ACL:
1. Connect your computer to the same network as the switch.
You can use a WiFi or wired connection to connect your computer to the network, or
connect directly to a switch that is off-network using an Ethernet cable.
2. Launch a web browser.
3. In the address field of your web browser, enter the IP address of the switch.
If you do not know the IP address of the switch, see
Discover or Change the Switch IP
Address on page 12.
The login window opens.
4. Enter the switch’s password in the Password
field.
The default password is password.
The System Information page displays.
5. Select Security
> ACL
> Advanced > IP ACL.
The IP ACL Configuration page displays.
6. Select the check box that is associated with the IP ACL.
7. Click the Delete
button.
The IP ACL is removed.
Configure Rules for a Basic IP ACL
You can define rules for IP-based standard ACLs (basic ACLs). The access list definition
includes rules that specify whether traffic matching the criteria is forwarded normally or
discarded.
Note: An implicit deny all rule is included at the end of an ACL list. This
means that if an ACL is applied to a packet, and if none of the explicit
rules match, then the final implicit deny all rule applies and the packet
is dropped.
Add a Rule for a Basic IP ACL
To add a rule for a basic IP ACL:
1. Connect your computer to the same network as the switch.
You can use a WiFi or wired connection to connect your computer to the network, or
connect directly to a switch that is off-network using an Ethernet cable.
To Next Page
