S350 Series 24-Port (PoE+) and 48-Port Gigabit Ethernet Smart Managed Pro Switches
Monitor the System User Manual306
View or Clear EAP and EAPoL Statistics
You can view information about Extensible Authentication Protocol (EAP) and EAP over LAN
(EAPoL) packets that are received on physical ports.
To view or clear EAP and EAPoL statistics:
1. Connect your computer to the same network as the switch.
You can use a WiFi or wired connection to connect your computer to the network, or
connect directly to a switch that is off-network using an Ethernet cable.
2. Launch a web browser.
3. In the address field of your web browser, enter the IP address of the switch.
If you do not know the IP address of the switch, see
Discover or Change the Switch IP
Address on page 12.
The login window opens.
4. Enter the switch’s password in the Password field.
The default password is
password.
The System Information page displays.
5. Select Monitoring > Ports > EAP Statistics.
The previous figure does not show all fields on the EAP Statistics page.
6. To refresh the page with the latest information about the switch, click the Refresh button.
7. To clear the counters, which r
esets the EAP and EAPoL statistics to default values, take
one of the following actions:
• T
o clear the counters for a specific port, select the check box associated with the port,
and click the Clear
button.
EAPOL Frames Transmitted The number of EAPoL frames of any type that were transmitted by this
authenticator.
Time Since Counters Last
Cleared
The elapsed time in days, hours, minutes, and seconds since the statistics for
the port were last cleared.
Table 67. Detailed port statistics (continued)
Field Description
