NETGEAR GS324T User Manual

S350 Series 24-Port (PoE+) and 48-Port Gigabit Ethernet Smart Managed Pro Switches
Monitor the System User Manual305
Total Packets Transmitted The number of frames that were transmitted by the port.
Unicast Packets Transmitted The total number of packets that higher-level protocols requested be transmitted
to a subnetwork-unicast address, including those that were discarded or not
sent.
Multicast Packets
T
ransmitted
The total number of packets that higher-level protocols requested be transmitted
to a multicast address, including those that were discarded or not sent.
Broadcast Packets
Transmitted
The total number of packets that higher-level protocols requested be transmitted
to the broadcast address, including those that were discarded or not sent.
T
ransmit Packets Discarded The number of outbound packets which were chosen to be discarded even
though no errors were detected to prevent them from being delivered to a
higher-layer protocol. A possible reason for discarding a packet could be to free
up buf
fer space.
Total Transmit Errors The sum of single, multiple, and excessive collisions.
Tx FCS Errors The total number of packets sent with a length (excluding framing bits, but
including FCS octets) of between 64 and 1518 octets, inclusive, but included a
bad frame check sequence (FCS) with an integral number of octets.
Total Transmit Packets
Discarded
The sum of single collision frames discarded, multiple collision frames
discarded, and excessive frames discarded.
Single Collision Frames The number of successfully transmitted frames on a particular interface for
which transmission is inhibited by exactly one collision.
Multiple Collision Frames The number of successfully transmitted frames on a particular interface for
which transmission is inhibited by more than one collision.
Excessive Collision Frames The number of frames for which transmission on a particular interface fails due
to excessive collisions.
Dropped Transmit Frames The number of transmit frames discarded at the selected port.
STP BPDUs Received The number of STP BPDUs received at the selected port.
STP BPDUs Transmitted The number of STP BPDUs transmitted from the selected port.
RSTP BPDUs Received The number of RSTP BPDUs received at the selected port.
RSTP BPDUs Transmitted The number of RSTP BPDUs transmitted from the selected port.
MSTP BPDUs Received The number of MSTP BPDUs received at the selected port.
MSTP BPDUs Transmitted The number of MSTP BPDUs transmitted from the selected port.
802.3x Pause Frames
T
ransmitted
The number of MAC control frames transmitted on the interface with an opcode
indicating the PAUSE operation.
This counter does not increment when the
interface is operating in half-duplex mode.
EAPOL Frames Received The number of valid EAPoL frames of any type that were received by this
authenticator
.
Table 67. Detailed port statistics (continued)
Field Description

NETGEAR GS324T Specifications

General

Switch type	Managed
Switch layer	L2/L3/L4
ARP inspection	Yes
Master (outer) case width	270 mm
Master (outer) case height	271 mm
Master (outer) case length	481 mm
Master (outer) case weight	8850 g
Harmonized System (HS) code	85176990
Quantity per master (outer) case	3 pc(s)
Package type	Box
Package depth	465 mm
Package width	229 mm
Package height	79 mm
Package weight	2710 g
Cables included	AC
Stackable	-
Product color	Black
Input current	5 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	13.5 W
Operating temperature (T-T)	0 - 40 °C
MAC address table	16000 entries
Power connector	AC-in jack
SFP module slots quantity	2
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Number of VLANs	256
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3az, IEEE 802.3x
Virtual LAN features	Private VLAN, Voice VLAN, Port-based VLAN
DHCP features	DHCP client

Weight and Dimensions

Depth	169 mm
Width	328 mm
Height	43 mm
Weight	1620 g
