NETGEAR GS324T User Manual

S350 Series 24-Port (PoE+) and 48-Port Gigabit Ethernet Smart Managed Pro Switches
Configure Quality of Service User Manual186
- 802.1p. IEEE 802.1p specifies eight priority tags (p0 to p7). The QoS setting
lets you map each of the eight priority levels to an internal hardware priority
queue. Models GS324T and GS324TP support four hardware queues (0 to 3)
and model GS348T supports eight hardware queues (0 to 7). The default
mode is 802.1p.
- DSCP.
The six most significant bits of the DiffServ field are called the
Dif
ferentiated Services Code Point (DSCP) bits.
• To configure CoS settings per interface, do the following:
a. Select the
Interface radio button.
b. From the Interface T
rust Mode
menu, select one of the following trust mode
options:
- Untrusted. Do not trust any CoS packet marking at ingress.
- 802.1p. IEEE 802.1p specifies eight priority tags (p0 to p7). The QoS setting
lets you map each of the eight priority levels to an internal hardware priority
queue. Models GS324T and GS324TP support four hardware queues (0 to 3)
and model GS348T supports eight hardware queues (0 to 7).
The default
mode is 802.1p.
- DSCP.
The six most significant bits of the DiffServ field are called the
Dif
ferentiated Services Code Point (DSCP) bits.
7. Click the Apply button.
Your settings are saved.
Configure CoS Interface Settings for an Interface
You can configure the trust mode for one or more interfaces and apply an interface shaping
rate to all interfaces or to a specific interface.
To configure CoS settings for an interface:
1. Connect your computer to the same network as the switch.
You can use a WiFi or wired connection to connect your computer to the network, or
connect directly to a switch that is off-network using an Ethernet cable.
2. Launch a web browser.
3. In the address field of your web browser, enter the IP address of the switch.
If you do not know the IP address of the switch, see
Discover or Change the Switch IP
Address on page 12.
The login window opens.
4. Enter the switch’s password in the Password
field.
The default password is password.
The System Information page displays.

NETGEAR GS324T Specifications

General

Switch type	Managed
Switch layer	L2/L3/L4
ARP inspection	Yes
Master (outer) case width	270 mm
Master (outer) case height	271 mm
Master (outer) case length	481 mm
Master (outer) case weight	8850 g
Harmonized System (HS) code	85176990
Quantity per master (outer) case	3 pc(s)
Package type	Box
Package depth	465 mm
Package width	229 mm
Package height	79 mm
Package weight	2710 g
Cables included	AC
Stackable	-
Product color	Black
Input current	5 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	13.5 W
Operating temperature (T-T)	0 - 40 °C
MAC address table	16000 entries
Power connector	AC-in jack
SFP module slots quantity	2
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	24
Number of VLANs	256
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3az, IEEE 802.3x
Virtual LAN features	Private VLAN, Voice VLAN, Port-based VLAN
DHCP features	DHCP client

Weight and Dimensions

Depth	169 mm
Width	328 mm
Height	43 mm
Weight	1620 g
