S350 Series 24-Port (PoE+) and 48-Port Gigabit Ethernet Smart Managed Pro Switches
Monitor the System User Manual309
10/100 Ethernet adapter then the cable status might be Open or Short because some
Ethernet adapters leave unused wire pairs unterminated or grounded.
The following table describes the nonconfigurable information displayed on the page.
Table 69. Cable Test information
Field Description
Cable Status Indicates the cable status:
• Normal. The
cable is
working correctly.
• Open. The cable is
disconnected or a faulty connector exists.
• Short. An electrical short exists in the cable.
• Cable T
est Failed. The cable status could not be determined. The cable might in fact
be working.
• Untested
. The
cable is
not yet tested.
• Invalid cable type. The cable type
is unsupported.
• No cable. The cable is
not present.
Cable Length The estimated length of the cable in meters. The length is displayed as a range between
the shortest estimated length and the longest estimated length. Unknown is displayed if the
cable length could not be determined. The cable length is displayed only if the cable status
is Normal.
Failure Location The estimated distance in meters from the end of the cable to the failure location. The
failure location is displayed only if the cable status is Open or Short.
Configure and View Logs
The switch generates messages in response to events, faults, or errors occurring on the
platform as well as changes in configuration or other occurrences. These messages are
stored locally and can be forwarded to one or more centralized points of collection for
monitoring purposes or long-term archival storage. Local and remote configuration of the
logging capability includes filtering of messages logged or forwarded based on severity and
generating component.
Manage the Memory Logs
The memory log stores messages in memory based upon the settings for message
component and severity. You can set the administrative status and behavior of logs in the
system buffer. These log messages are cleared when the switch reboots.
To configure the memory log settings and view or clear the memory log:
1. Connect your computer to the same network as the switch.
You can use a WiFi or wired connection to connect your computer to the network, or
connect directly to a switch that is off-network using an Ethernet cable.
2. Launch a web browser.
