S350 Series 24-Port (PoE+) and 48-Port Gigabit Ethernet Smart Managed Pro Switches
Configure System Information User Manual76
13. From the Timer Schedule menu, select a timer schedule or select None, which is the
default selection.
For information about setting up and configuring PoE timer schedules, see
Set Up PoE
Timer Schedules on page 106.
14. Click the Apply button.
Your settings are saved.
The following table describes the nonconfigurable fields on the page.
Table 22. PoE Port Configuration
Field Description
High Power All ports supports high power mode.
Max Power (W) The maximum power in watts that can be provided by the port.
Class The class defines the range of power that a powered device (PD) is drawing from
the switch.
The class definitions are as follows:
• 0: 0.44–16.2W
• 1: 0.44–4.2W
• 2: 0.44–7.4W
• 3: 0.44–16.2W
• 4: 0.44–31.6W
• Unknown
.
The class cannot be detected, or no PD is attached to the port.
Output V
oltage (Volts) The voltage that is delivered to the PD in volts.
Output Current (mA) The current that is delivered to the PD in mA.
Output Power (W) The power that is delivered to the PD in watts.
Status The operational status of the port:
• Disabled. No power is delivered.
• Delivering Power. Power is being drawn by the PD.
• Requesting Power.
The port is requesting power
.
• Fault. A problem
occurred with the power.
• Test. The port is in test mode.
• Other
Fault. The port is idle because of an error condition.
• Searching
. The port is not in one of the other states in this list.
