Page | 112
FIGURE 10-10
Complementing this feature, TriCaster provides Look Ahead Preview monitoring capability for M/Es as well
(Figure 10-10). The Viewport Options menu group Outputs lists a special M/E Preview option for this purpose.
Hint: All viewports assigned as M/E Previews show output from the same M/E. Making an M/E tab
selection updates all viewports when Tabs Follow all Delegates is enabled.
Just like the main Look Ahead Preview, the M/E Preview respects Delegate selections made in the Transition
section of the assigned M/E, showing you the display that will result from the currently configured (M/E)
Take/Auto operation.
