Oce PlotWave 340 User Manual

The Hardware
The components of the printer (front)
Illustration
8
7
1
2
3
4
9
10
11
12
65
Component - function table
#
Description / FunctionComponentNr
Remove this cover when you want to move
the printer.
lower left front cover1
Located at the front, used for error recov-
ery.
lower front cover2
To manually feed cut-sheets up to 36"
width.
media bypass3
Compartment to refill toner.toner compartment4
Only available in printer-only version.printer top cover5
Delivery tray that collects the printed
sheets.
top delivery tray6
Chapter 2 - Get to Know the Printing System28
The components of the printer (front)

Oce PlotWave 340 Specifications

General

Print Resolution	600 x 1200 dpi
Maximum Roll Width	36 inches
Memory	2 GB
Hard Drive	500 GB
Maximum Print Length	Unlimited
Maximum Print Width	36 inches
Media Handling	Roll feed
Connectivity	Ethernet 10/100/1000Base-T
Media Width	297 - 914 mm
Media Types	Recycled
Media Thickness	0.07 - 0.3 mm
Operating Systems Supported	Windows, Linux
