Oce PlotWave 340 User Manual

The user panel: Océ ClearConnect
Illustration
1
1
2
3
4
5
6
Components of the Océ ClearConnect
#
Description / FunctionComponentNr
Light that gives feedback on the status of the
printer.
status light1
Button that allows the operator to get the
printer out of sleep mode.
wake-up button2
Port to insert a USB mass storage device into.USB port3
Button that allows the operator to stop the
printer and scanner.
stop button4
Button to return to the home screen on the
user panel display.
home button5
Dynamic tile on the user panel display that
allows the operator to start a scan, print, or
copy job.
green button (touch)6
Chapter 2 - Get to Know the Printing System 33
The user panel: Océ ClearConnect

Oce PlotWave 340 Specifications

General

Print Resolution	600 x 1200 dpi
Maximum Roll Width	36 inches
Memory	2 GB
Hard Drive	500 GB
Maximum Print Length	Unlimited
Maximum Print Width	36 inches
Media Handling	Roll feed
Connectivity	Ethernet 10/100/1000Base-T
Media Width	297 - 914 mm
Media Types	Recycled
Media Thickness	0.07 - 0.3 mm
Operating Systems Supported	Windows, Linux
