Oce PlotWave 340 User Manual

The media drawer
Illustration
1
2
3
5
4
Component - function table
#
Description / FunctionComponentNr
Carries the media rollroll holder1
Media placed on roll holder in first position.media roll 12
Media placed on roll holder in second position.
Note:
The scanner calibration sheet is located at
the back of roll 2.
media roll 2 (optional)3
Groove integrated behind the front cover of the
media drawer, on which the media can be easily
loaded.
roll loading station4
Button used to trim a strip of a new or damaged
media roll.
clean cut button5
Chapter 2 - Get to Know the Printing System32
The media drawer

Oce PlotWave 340 Specifications

General

Print Resolution	600 x 1200 dpi
Maximum Roll Width	36 inches
Memory	2 GB
Hard Drive	500 GB
Maximum Print Length	Unlimited
Maximum Print Width	36 inches
Media Handling	Roll feed
Connectivity	Ethernet 10/100/1000Base-T
Media Width	297 - 914 mm
Media Types	Recycled
Media Thickness	0.07 - 0.3 mm
Operating Systems Supported	Windows, Linux
