Oce PlotWave 340 User Manual

8.
If necessary, press the clean cut button to trim a strip of the new media roll. Press once
for a strip of approximately 20 cm, or hold the button and release it when the strip has
the desired length.
9.
Close the media drawer.
Note:
Do not open the media drawer during loading.
10.
The user panel displays the message that new media is detected. Follow the steps in the
wizard to define the correct media type and size, when not detected automatically.
Chapter 5 - Maintain the Printing System 303
Load a media roll (position 1)

Oce PlotWave 340 Specifications

General

Print Resolution	600 x 1200 dpi
Maximum Roll Width	36 inches
Memory	2 GB
Hard Drive	500 GB
Maximum Print Length	Unlimited
Maximum Print Width	36 inches
Media Handling	Roll feed
Connectivity	Ethernet 10/100/1000Base-T
Media Width	297 - 914 mm
Media Types	Recycled
Media Thickness	0.07 - 0.3 mm
Operating Systems Supported	Windows, Linux
