Oce PlotWave 340 User Manual

•
The original support rollers (6)
Rotate the rollers to clean them.
•
The transparent contact plates (9)
Wipe off any soiled areas.
3.
Wipe all the cleaned parts once again using a dry Muslin towel.
Caution:
Watch out, not to get your fingers caught in the scanner top cover.
4.
Press the scanner top cover down gently with both hands, to close it.
Note:
Check that the left and right scanner open levers are locked into position.
Chapter 5 - Maintain the Printing System318
Clean the scanner

Oce PlotWave 340 Specifications

General

Print Resolution	600 x 1200 dpi
Maximum Roll Width	36 inches
Memory	2 GB
Hard Drive	500 GB
Maximum Print Length	Unlimited
Maximum Print Width	36 inches
Media Handling	Roll feed
Connectivity	Ethernet 10/100/1000Base-T
Media Width	297 - 914 mm
Media Types	Recycled
Media Thickness	0.07 - 0.3 mm
Operating Systems Supported	Windows, Linux
