288 Appendix A Specifications of the Océ TCS500
Standard scale factor
Standard scale factor
Introduction
The Océ TCS500 can scale (reduce and enlarge) the image to a defined format.
The overview below shows the scale factor if you need to copy on media of different
sizes.
Attention: If you select the wrong scale factor you can loose information.
Supported DIN media series
The table shows the scale factor if you copy from one media size (original column)
to another media size (first row)
[101]
[101] DIN table
Originals Standard scale fixed steps for the DIN media series [%]
A0 A1 A2 A3 36 Inch B1 B2
A0 100 71 50 35 109 84 59
A1 141 100 71 50 153 119 84
A2 200 141 100 71 218 168 119
A3 283 200 141 100 308 238 168
36 Inch 107 65 46 32 100 77 55
B1 119 84 59 42 129 100 71
B2 168 119 84 59 183 141 100
