Connecting to the PC after preparing the device
- 28 -
It also comes with anti-tip feet to avoid the risk of tipping. It is recommended to use it when the expansion tray
is installed.
A Phillips-head screwdriver and a flat-head screwdriver are required to install the caster stand.
To install any of the three expansion trays is installed, be sure to install the dedicated caster stand, the anti-tip feet
and the attached fixing parts to avoid the risk of tipping.
The packing box and buffer materials are required to ship the dedicated caster stand. Do not discard them, but store
them safely.
Model: BOD-S3
Doing so may cause injury.
This machine weighs approx. 30 kg, so be sure to have it lifted by at least 2 persons.
1
Check that you have all the parts for the dedicated caster stand.
(1) Main unit
(2) Anti-tip foot a
(3) Anti-tip foot b (x 3)
(4) Positioning pin (x 2)
(5) Metal fixtures of the caster stand (x 2)
(6) Screw (x 4)
2
Mount the anti-tip foot a on the front of the dedicated caster stand.
