- 24 -
1. Basic Operations
• E-mail Setting
•Test Print
Wireless
Setting (If
wireless LAN
module fitted)
WPS WPS-PBC WPS-PBC is executed.
WPS-PIN WPS-PIN is executed.
Search A list of access point name found in the
search
Displays a list of wireless LAN access
points' names that are found in a
search.
Manual Setup SSID Enter an SSID.
Security Selects the security of the wireless LAN
function.
"WPA-EAP" and "WPA2-EAP" can be
set only in Web.
WEP Key Enter WEP Key.
Displays if [WEP] is selected for
[Security].
WPA Encryption Type Select a WPA/WPA2-PSK or WPA2-
PSK encryption type.
Displays if [WPA/WPA2-PSK] or
[WPA2-PSK] is selected for [Security].
WPA Pre-shared Key Enter the Pre-shared Key.
Displays if [WPA/WPA2-PSK] or
[WPA2-PSK] is selected for [Security].
Reconnect Wireless reconnection is executed.
Obtaining IP address Sets to obtain the IP address
automatically or manually.
IP Address Sets the IP address. You can enter up
to 15 characters.
Subnet Mask Sets the subnet mask. You can enter
up to 15 characters.
Default Gateway Sets the gateway address. You can
enter up to 15 characters.
DNS Server (Primary) Sets the IP address for a Primary DNS
server. You can enter up to
15 characters.
DNS Server (Secondary) Sets the IP address for a Secondary
DNS server. You can enter up to
15 characters.
WINS Server (Primary) Sets the name or the IP address for the
WINS server. You can enter up to
15 characters.
WINS Server (Secondary) Sets the name or the IP address for the
WINS server. You can enter up to
15 characters.
Item Description
Description
Mail Server Address Sets the IP address or host name for
the SMTP server. You can enter up to
64 characters.
Set Sender's Address (From) Sets an e-mail address for this
machine.
Receive Setting Sets the protocol to be used for
receiving e-mails.
Authentication Method Sets the authentication method.
SMTP User ID Sets the login ID to the server used for
SMTP authentication. You can enter up
to 64 characters.
SMTP Password Sets the password to the server used
for SMTP authentication. You can enter
up to 64 characters.
POP3 Server Sets the IP address or host name for
the POP3 server. You can enter up to
64 characters.
POP User ID Sets the login ID to the server used for
POP authentication. You can enter up
to 64 characters.
POP Password Sets the password to the server used
for POP authentication. You can enter
up to 16 characters.
Test Sends a test mail to the Mail Server.
You can check if communication
between your machine and the mail
server works normally.
Item Description
Test Print Performing test printing allows you to check if
the consumables and paper are properly set.
To Next Page
