- 416 -
11. Utility Software
7
Select [Do not allow unsecured communication] on the [Communicating with
computers that do not support IPsec] screen, and then click [Next].
8
Select [Custom] on the [IP Traffic Security] screen, and then click [Settings].
9
Set in the [Custom Security Method Settings] window, and then click [OK].
Set the same values as those specified in [ESP Encryption Algorithm], [ESP Authentication Algorithm], [AH
Authentication Algorithm], and [LifeTime] in the "Phase2 Proposal" setting in "Setting This Machine".
10
Click [Next] on the [IP Traffic Security] screen.
11
Select the [Edit Properties] check box, and then click [Finish].
Assigning an IP Security Policy
1
If you want to enable Key PFS, select the [Use session key perfect forward
secrecy (PFS)] check box in the [Filter Action Properties] window.
2
If you perform IPSec communication with the IPv6 global address, select the
[Accept unsecured communication, but always respond using IPsec] check
box.
3
Click [OK].
4
Select the new filter action, and then click [Next].
5
Select the authentication method on the [Authentication Method] screen, and
then click [Next].
If the pre-shared key is set in "Setting This Machine", enable "Use this string to protect the key exchange
(preshared key)" on the [Authentication Method] screen and enter the pre-shared key.
6
Click [Finish].
7
Click [OK] in the New IP Security Policy Properties window.
8
Select the new IP security policy in the [Local Security Policy] window.
9
Select [Assign] from the [Action] menu.
10
Check that [Yes] is displayed for [Policy Assigned] for the new IP security
policy.
11
Click [x] in the [Local Security Policy] window.
To Next Page
