- 420 -
11. Utility Software
13
Connect the LAN cable to the network interface connector.
14
Connect the LAN cable to the authentication port of an authentication switch.
15
Turn the machine on.
16
Set up this machine.
Setting by Using EAP-TLS
EAP authentication must be performed after computer connection is authenticated by
enabling IEEE802.1X. This section describes how to set EAP-TLS, which is an EAP
authentication type.
Set up this machine and the computer before following the procedure below.
You must log in as the administrator to complete this setting.
1
Open the Web page of this machine.
Open the Web Page of This Machine
2
Log in as the administrator.
3
Select [Admin Setup].
4
Select [Network] > [IEEE802.1X].
5
Select [Enable] for [IEEE802.1X].
6
Select [EAP-TLS] for [EAP Type].
7
Enter a user name in [EAP User].
8
Select [Do not use SSL/TLS Certificate for EAP authentication], and then click
[Import].
9
Enter the file name of the certificate.
You can only import a PKCS#12 file.
10
Enter the password of the certificate, and then click [OK].
11
Select [Authenticate Server], and then click [Import].
12
Enter the file name of the CA certificate, and then click [OK].
Specify the certificate issued by the certificate authority that the RADIUS server
obtained. You can import a PEM, DER, and PKCS#7 file.
13
Click [Submit].
The new settings take effect when the network function of this machine restarts.
14
Turn the machine off after this machine becomes online.
15
Connect the LAN cable to the network interface connector.
16
Connect the LAN cable to the authentication port of an authentication switch.
17
Turn the machine on.
18
Set up this machine.
